High Content Screening
Mechanical Design | Static sample holder, moving optics block |
Linear Motors with absolute position encoder 1nm resolution | |
XY axis | 120 mm x 80 mm, 1nm resolution |
Z axis | 25 mm, 1nm resolution |
Objectives | 2x, 4x, 10x, 20x, 40x (Nikon) |
LED Light | Omicron LED-HUB, up to 6 modules parallel |
385,405, 455, 470, 505, 528, 595, 625 nm | |
> 15,000 hours on-time | |
LED power sensor at MT plate level | |
Fluo Filter | Custom type, up to 5 |
Any 25mm “Semrock” combination | |
Ultra fast switching | |
Camera | Hamamatsu sCMOS 2kx2k |
Environmental Control | Robotic lid + integrated laminar flow, pressure free |
20oC – 40oC if T > ambient temp | |
Focusing | Laser autofocus @ 780 nm |
Image based autofocus (standard, yeast) | |
Remote Control | optional via TCP based commands from any software |
Ambient Conditions | 18o-25oC (Indoor use) |
Relative humidity 30% – 80% (without condensation) | |
Power | 120V – 240V |
Weight | 62 kg |
H x W x D | 553mm x 528mm x 555mm |
